DHF08-223/SV08-23
Longli
8412299090
DESCRIPTION
A solenoid-operated, 2-way, normally open, poppet-type, screw-in hydraulic cartridge valve designed for low leakage in load-holding applications.
OPERATION
When de-energized, the DHF08-223 allows flow from 2 to 1, and from 1 to 2. When energized, the valve closes, blocking flow from 2 to 1. In this mode, flow from 1 to 2 will be allowed after overcoming the solenoid force. This requires 3.4 to 10.3 bar (50 to 150 psi).
Operation of Manual Override Option: To override, push and hold override button.
FEATURES
• Continuous-duty rated coil.
• Hardened seat for long life and low leakage.
• Optional coil voltages and terminations.
• Cartridges are voltage interchangeable.
• Unitized, molded coil design.
• Manual override option.
• Optional waterproof E-Coils rated up to IP69K.
• Industry common cavity.
• Compact size.
Model: DHF08-223
Place of Origin: Shandong,China (Mainland)
Product: Hydraulic 2 Way 2 Position Solenoid Valve(Normally Closed)
Description: With small size, light weight, low cost for unit
Materials: free-machining steel
Working pressure: 250bar
Flow: 30L/min
Voltage: 12V, 24V, 110V, 220V
Customized design: Available, as per drawings or samples
OEM/ODM business: Acceptable, please contact us
Quality tested: High pressure testing before delivery
